Double Siren

Authors
Date(s)
Details

The double siren was one of Koenig’s more popular instruments. It consisted of two “polyphonic” or “multivoiced” sirens with more than one series of holes, and was an invention of the German physicist and former teacher of Hermann von Helmholtz, Heinrich Wilhelm Dove (1803–1879). It produced several pure tones simultaneously, in musical chords, and under greater pressure. It was ideal for demonstrating interference effects (when sound waves combined to amplify or diminish each other) and combination tones. [Pantalony 2009, 184-185]

Videos

Close-ups of the Helmholtz Double Siren

Screenshot



Adjusting the phase of the Helmholtz Double Siren

Screenshot 2



Adjusting the stops on the Helmholtz Double Siren

Screenshot 3



Running the Helmholtz Double Siren

Screenshot 4



Accession Number: 2013.ph.607

Location: University of Toronto, Collections Storage

Description: This siren consists of two wide brass cylindrical chambers, one above the other, each covered with a rotating perforated disk and supported in a brass and iron framework set on a wooden base. To the top of the top cylinder and the bottom of the lower cylinder are affixed angled pipes. The two chambers are connected to one another at their centres by a steel rod. On the sides of each cylinder are four brass knobs affixed to rods that may be pulled in and out. Between these two chambers is brass case with two dials on the front, each connected to a gear in the back. A set of interlocked gears on the top of the upper cylinder is attached to a small handle on the top of the framework.

Materials: Iron Alloy, Copper Alloy, Wood, Glass

Markings: The dial on the left is marked with numbers from 0 to 100 in intervals of 10. The dial on the right is marked with numbers from 0 to 25 in intervals of 5. Three of the four knobs on the top cylinder are marked "12", "15", and "16". The four knobs on the bottom cylinder are marked "18", "8", "12", and "10". On the top of the framework is stamped "RUDOLPH KOENIG A PARIS". On the bottom of the wooden base is written "NO 2" in pencil.

Dimensions: Height =46.5, Width = 25, Length= 26

Function: This piece was used primarily in demonstration rather than experiment. It shows the effects of pure tones produced simultaneously by pressurized air, including interference and combination tones.

Condition: Very good: the piece is fully functional. Some minor tarnishing on the brass.

Marker: Rudolph Koenig

Date: c. 1878

Provenience: University of Toronto Physics Department

Historical Notes: With the help of the Berlin mechanic, Sauerwald, Helmholtz created this instrument in 1855-56. It was later produced by the Paris-based instrument maker Rudolph Koenig. The double siren was one of Koenig's more popular instruments. It consisted of two polyphonic or multivoiced sirens with more than one series of holes, and was an invention of the German physicist and former teacher of Hermann von Helmholtz, Heinrich Wilhelm Dove (1803-1879). It produced several pure tones simultaneously, in musical chords, and under greater pressure. It was ideal for demonstrating interference effects (when sound waves combined to amplify or diminish each other) and combination tones). [Pantalony 2009, 184-185]

Additional Information and References: A description of this siren and similar sirens can be found in David Patalony's "Altered Sensations: Rudolph Koenig's Accoustical Workshop in Nineteenth-Century Paris" New York: Springer, 2009, pp.184-186.
