Organ pipe

Authors
Date(s)
Details

Organ pipes came in a variety of forms, each producing desired overtones.

Different organ pipes from the collection of antique physics instruments
Fig. 1: Different organ pipes from the collection of antique physics instruments

The pipes used in musical instrument research often feature specific additions for making certain adjustments or performing certain tests. Besides the traditional pipes made of wood, zinc, tin, etc, there were pipes that produced a range of tones by way of an adjustable, graduated piston; pipes with adjustable membranes for producing different vibratory effects; pipes with adjustable holes for the measurement of pressure; pipes for studying the effect of the position of the mouthpiece on the tone; and yet other pipes demonstrating the influence on tone of the volume and shape of the pipe.

 Kundt’s covered pipe, by Max Kohl
Fig. 2: Kundt’s covered pipe, by Max Kohl

An interesting piece in the collection, purchased from Max Kohl of Chemnitz, is called Kundt’s covered pipe (fig. 2). Three glass tubes filled with water allow one to observe the differences in air pressure at various locations inside the pipe. This allows one to locate the positions of the nodes and antinodes of the standing waves.

Text & figures by Brian Tinker, republished with the kind permission of Case Western Reserve University and William Fickinger, Prof Emeritus of Physics.
